clm 系列

项目

工作温度范围

额定电压范围

静电容量容许差

漏电流

损失角正切值（tanδ）

额定电压（vdc）

160v～400v

420v～450v

tanδmax

0.15

0.20

额定电压（vdc）

160v～400v

420v～500v

z(-25℃)/z( 20℃)

4

8

静电容量变化率

≤初始值的±20%

损失角正切值

≤初始规格值的200%

漏电流

≤初始规格值

静电容量变化率

≤初始值的±20%

损失角正切值

≤初始规格值的200%

漏电流

≤初始规格值

工作电压

额定容量

外壳尺寸d x l

损失角正切值

额定纹波电流

[v]

[μf]

[mm]

（tanδ）

（ams/105℃,120hz）

4700

22×20

0.16

1.6

clm160hzn472mp20

4700

22×25

0.16

1.77

clm160hzn472mp25

6800

22×25

0.11

2.6

clm160hzn682mp25

6800

25×20

0.11

1.8

clm160hzn682mq20

8200

22×25

0.09

3.1

clm160hzn822mp25

10000

22×30

0.075

3.8

clm160hzn103mp30

10000

25×25

0.143

3.8

clm160hzn103mq25

10000

30×20

0.084

2.4

clm160hzn103mr20

12000

22×30

0.119

4.5

clm160hzn123mp30

12000

25×25

0.119

4.5

clm160hzn123mq25

15000

22×35

0.054

5.3

clm160hzn153mp35

15000

25×30

0.054

5.3

clm160hzn153mq30

15000

35×20

0.055

3.2

clm160hzn153ma20

18000

22×40

0.045

5.6

clm160hzn183mp40

18000

25×30

0.045

5.6

clm160hzn183mq30

22000

22×45

0.065

6.1

clm160hzn223mp45

22000

25×35

0.065

6.1

clm160hzn223mq35

22000

30×30

0.065

6.1

clm160hzn223mr30

27000

25×45

0.031

6.3

clm160hzn273mq45

27000

30×35

0.031

6.3

clm160hzn273mr35

33000

25×50

0.025

6.8

clm160hzn333mq50

33000

30×40

0.025

6.8

clm160hzn333mr40

33000

35×30

0.025

6.8

clm160hzn333ma30

39000

30×45

0.022

6.95

clm160hzn393mr45

39000

35×35

0.022

6.95

clm160hzn393ma35

47000

30×50

0.03

7.5

clm160hzn473mr50

47000

35×40

0.03

7.5

clm160hzn473ma40

56000

35×45

0.02

8.7

clm160hzn563ma45

56000

40×40

0.022

9

clm160hzn563mu40

68000

35×50

0.018

9

clm160hzn683ma50

82000

35×63

0.016

10

clm160hzn823ma63

82000

40×50

0.016

10.3

clm160hzn823mu50

100000

35×80

0.015

11

clm160hzn104ma80

100000

40×63

0.018

11.4

clm160hzn104mu63

120000

35×105

0.014

12.81

clm160hzn124maa5

120000

40×80

0.017

12.4

clm160hzn124mu80

120000

50×50

0.014

13.17

clm160hzn124mc50

150000

50×63

0.012

14.4

clm160hzn154mc63

180000

40×105

0.013

14.85

clm160hzn184mua5

180000

50×80

0.011

15.69

clm160hzn184mc80

220000

50×92

0.01

16.73

clm160hzn224mc92

270000

50×105

0.009

17.79

clm160hzn274mca5

330000

50×130

0.008

18.31

clm160hzn334mcd0

120000

50×80

0.012

15.29

clm250hzn124mc80

150000

40×105

0.011

14.07

clm250hzn154mua5

150000

50×92

0.011

16.01

clm250hzn154mc92

180000

50×105

0.01

16.89

clm250hzn184mca5

2200

22×20

0.211

1.4

clm350hzn222mp20

2200

22×25

0.166

1.5

clm350hzn222mp25

3300

22×25

0.11

2.3

clm350hzn332mp25

3300

25×20

0.12

1.7

clm350hzn332mq20

3900

22×25

0.095

2.7

clm350hzn392mp25

4700

22×30

0.08

3.3

clm350hzn472mp30

4700

25×25

0.08

3.3

clm350hzn472mq25

4700

30×20

0.09

2

clm350hzn472mr20

5600

22×30

0.083

3.4

clm350hzn562mp30

5600

25×25

0.083

3.4

clm350hzn562mq25

6800

22×35

0.068

3.7

clm350hzn682mp35

6800

35×20

0.07

2.4

clm350hzn682ma20

6800

25×30

0.069

3.7

clm350hzn682mq30

8200

22×40

0.057

4

clm350hzn822mp40

8200

25×35

0.057

4

clm350hzn822mq35

10000

22×45

0.05

4.4

clm350hzn103mp45

10000

25×40

0.05

4.4

clm350hzn103mq40

10000

30×30

0.05

4.4

clm350hzn103mr30

10000

35×25

0.05

4.4

clm350hzn103ma25

12000

25×45

0.044

5.1

clm350hzn123mq45

12000

30×35

0.044

5.1

clm350hzn123mr35

12000

35×30

0.044

5.1

clm350hzn123ma30

15000

25×50

0.057

5.6

clm350hzn153mq50

15000

30×40

0.036

5.6

clm350hzn153mr40

15000

35×30

0.036

5.6

clm350hzn153ma30

18000

30×45

0.048

5.7

clm350hzn183mr45

18000

35×35

0.048

5.7

clm350hzn183ma35

22000

30×50

0.026

6.1

clm350hzn223mr50

22000

35×40

0.026

6.1

clm350hzn223ma40

27000

35×45

0.021

6.8

clm350hzn273ma45

27000

40×40

0.021

6.8

clm350hzn273mu40

33000

35×50

0.018

7.15

clm350hzn333ma50

33000

35×63

0.018

7.8

clm350hzn333ma63

39000

35×63

0.015

7.9

clm350hzn393ma63

39000

35×70

0.015

8.6

clm350hzn393ma70

39000

40×50

0.017

8

clm350hzn393mu50

47000

35×80

0.015

9.5

clm350hzn473ma80

47000

40×63

0.016

9.6

clm350hzn473mu63

56000

50×50

0.015

10.94

clm350hzn563mc50

27000

35×63

0.018

8.3

clm500hzn273ma63

27000

40×50

0.025

8.1

clm500hzn273mu50

31000

50×40

0.015

9.2

clm500hzn313mc40

31000

40×60

0.018

9.1

clm500hzn313mu60

33000

50×50

0.018

10.48

clm500hzn333mc50

47000

50×63

0.013

11.54

clm500hzn473mc63

47000

35×105

0.014

10.27

clm500hzn473maa5

56000

40×105

0.012

11.47

clm500hzn563mua5

56000

50×80

0.012

12.46

clm500hzn563mc80

68000

50×92

0.011

13.17

clm500hzn683mc92

82000

50×105

0.011

13.87

clm500hzn823mca5

1000

22×20

0.38

1.2

clm630hzn102mp20

1000

22×25

0.332

1.2

clm630hzn102mp25

1500

22×25

0.221

1.7

clm630hzn152mp25

1500

25×20

0.25

1.3

clm630hzn152mq20

2200

22×30

0.151

2.5

clm630hzn222mp30

2200

25×25

0.151

2.5

clm630hzn222mq25

2200

30×20

0.17

1.5

clm630hzn222mr20

2700

22×35

0.123

3.7

clm630hzn272mp35

2700

25×30

0.123

3.7

clm630hzn272mq30

3300

22×40

0.11

4.1

clm630hzn332mp40

3300

25×30

0.11

4.1

clm630hzn332mq30

3300

30×25

0.11

4.1

clm630hzn332mr25

3300

35×20

0.125

1.7

clm630hzn332ma20

3900

22×45

0.1

4.4

clm630hzn392mp45

3900

25×35

0.1

4.4

clm630hzn392mq35

3900

30×30

0.1

4.4

clm630hzn392mr30

4700

22×50

0.08

4.9

clm630hzn472mp50

4700

25×40

0.08

4.9

clm630hzn472mq40

4700

30×30

0.08

4.9

clm630hzn472mr30

4700

35×25

0.08

4.9

clm630hzn472ma25

5600

35×30

0.07

5.4

clm630hzn562ma30

5600

25×45

0.07

5.4

clm630hzn562mq45

5600

30×35

0.07

5.4

clm630hzn562mr35

6800

25×50

0.06

5.8

clm630hzn682mq50

6800

30×40

0.06

5.8

clm630hzn682mr40

6800

35×30

0.06

5.8

clm630hzn682ma30

8200

30×45

0.067

6

clm630hzn822mr45

8200

35×35

0.067

6

clm630hzn822ma35

10000

40×40

0.028

6.6

clm630hzn103mu40

10000

35×40

0.033

6.5

clm630hzn103ma40

12000

35×63

0.019

7.7

clm630hzn123ma63

12000

35×50

0.028

7.2

clm630hzn123ma50

3300

22×20

0.177

1.6

clm250hzn332mp20

3300

22×25

0.161

1.7

clm250hzn332mp25

4700

22×25

0.11

2.4

clm250hzn472mp25

4700

25×20

0.125

1.8

clm250hzn472mq20

5600

22×25

0..095

1.9

clm250hzn562mp25

6800

22×30

0.078

2.75

clm250hzn682mp30

6800

25×25

0.078

3.5

clm250hzn682mq25

6800

30×20

0.078

2.3

clm250hzn682mr20

8200

22×30

0.065

3.6

clm250hzn822mp30

8200

25×25

0.065

3.6

clm250hzn822mq25

10000

22×25

0.058

3.8

clm250hzn103mp25

10000

25×30

0.058

3.8

clm250hzn103mq30

10000

30×25

0.136

3.28

clm250hzn103mr25

10000

35×20

0.06

2.7

clm250hzn103ma20

12000

22×40

0.05

4.1

clm250hzn123mp40

12000

25×35

0.05

4.1

clm250hzn123mq35

12000

30×30

0.05

4.1

clm250hzn123mr30

15000

22×50

0.04

4.6

clm250hzn153mp50

15000

25×40

0.04

4.6

clm250hzn153mq40

15000

30×30

0.04

4.6

clm250hzn153mr30

18000

25×45

0.035

5.5

clm250hzn183mq45

18000

30×35

0.035

5.5

clm250hzn183mr35

22000

25×50

0.03

6.1

clm250hzn223mq50

22000

30×40

0.03

6.1

clm250hzn223mr40

27000

30×45

0.023

6.2

clm250hzn273mr45

27000

35×35

0.023

6.2

clm250hzn273ma35

33000

30×50

0.02

6.8

clm250hzn333mr50

33000

35×40

0.02

6.8

clm250hzn333ma40

33000

40×40

0.026

7.3

clm250hzn333mu40

39000

35×45

0.02

7.4

clm250hzn393ma45

39000

40×40

0.02

8

clm250hzn393mu40

47000

35×50

0.024

8

clm250hzn473ma50

47000

35×63

0.017

8.3

clm250hzn473ma63

56000

35×70

0.015

9.1

clm250hzn563ma70

56000

40×63

0.015

9.5

clm250hzn563mu63

56000

35×63

0.024

8.6

clm250hzn563ma63

56000

40×50

0.016

9

clm250hzn563mu50

68000

35×80

0.013

10.4

clm250hzn683ma80

68000

40×63

0.017

10.25

clm250hzn683mu63

82000

50×50

0.016

12.29

clm250hzn823mc50

100000

35×105

0.01

11.97

clm250hzn104maa5

100000

50×63

0.014

13.45

clm250hzn104mc63

100000

40×80

0.012

12

clm250hzn104mu80

56000

40×80

0.015

10.3

clm350hzn563mu80

68000

35×105

0.01

10.62

clm350hzn683maa5

68000

50×63

0.013

11.93

clm350hzn683mc63

82000

40×105

0.012

12.02

clm350hzn823mua5

82000

50×80

0.012

13.06

clm350hzn823mc80

100000

50×92

0.011

13.97

clm350hzn104mc92

120000

50×105

0.01

14.86

clm350hzn124mca5

1500

22×20

0.225

1.2

clm500hzn152mp20

1500

22×25

0.22

1.25

clm500hzn152mp25

2200

22×25

0.15

1.8

clm500hzn222mp25

2200

25×20

0.175

1.4

clm500hzn222mq20

2700

22×25

0.125

2.2

clm500hzn272mp25

3300

22×30

0.1

2.7

clm500hzn332mp30

3300

25×25

0.158

2.7

clm500hzn332mq25

3300

30×20

0.117

1.7

clm500hzn332mr20

3900

22×30

0.085

2.8

clm500hzn392mp30

3900

25×25

0.085

2.8

clm500hzn392mq25

4700

22×35

0.11

3

clm500hzn472mp35

4700

25×30

0.11

3

clm500hzn472mq30

4700

30×25

0.11

3

clm500hzn472mr25

4700

35×20

0.08

2.1

clm500hzn472ma20

5600

22×40

0.06

3.4

clm500hzn562mp40

5600

25×35

0.06

3.4

clm500hzn562mq35

5600

30×30

0.06

3.4

clm500hzn562mr30

6800

22×50

0.05

3.9

clm500hzn682mp50

6800

25×40

0.05

3.9

clm500hzn682mq40

6800

30×30

0.05

3.9

clm500hzn682mr30

8200

25×45

0.04

4.4

clm500hzn822mq45

8200

30×35

0.04

4.4

clm500hzn822mr35

10000

25×50

0.04

5

clm500hzn103mq50

10000

30×40`

0.04

5

clm500hzn103mr40

10000

35×30

0.04

5

clm500hzn103ma30

12000

30×45

0.033

5.6

clm500hzn123mr45

12000

35×35

0.033

5.6

clm500hzn123ma35

15000

30×50

0.037

6.4

clm500hzn153mr50

15000

35×40

0.037

6.4

clm500hzn153ma40

18000

35×63

0.018

7.8

clm500hzn183ma63

18000

35×45

0.022

6.9

clm500hzn183ma45

18000

40×40

0.023

6.94

clm500hzn183mu40

22000

35×70

0.025

8.6

clm500hzn223ma70

22000

35×50

0.025

7.6

clm500hzn223ma50

27000

35×80

0.013

9.3

clm500hzn273ma80

27000

40×63

0.018

9

clm500hzn273mu63

12000

40×40

0.035

7.15

clm630hzn123mu40

15000

35×70

0.016

8.5

clm630hzn153ma70

15000

35×63

0.028

7.7

clm630hzn153ma63

18000

35×80

0.023

9.4

clm630hzn183ma80

18000

40×63

0.028

9.25

clm630hzn183mu63

27000

40×80

0.018

10

clm630hzn273mu80

27000

35×105

0.015

10.38

clm630hzn273maa5

27000

50×50

0.018

10.86

clm630hzn273mc50

33000

40×105

0.015

11.76

clm630hzn333mua5

33000

50×63

0.017

11.57

clm630hzn333mc63

47000

50×80

0.013

12.78

clm630hzn473mc80

51000

50×92

0.012

13.34

clm630hzn513mc92

56000

50×105

0.012

13.93

clm630hzn563mca5

680

22×20

0.45

1

clm800hzn681mp20

680

22×25

0.39

1

clm800hzn681mp25

1000

22×25

0.265

1.5

clm800hzn102mp25

1000

25×20

0.3

1.2

clm800hzn102mq20

1200

22×25

0.22

1.8

clm800hzn122mp25

1500

22×30

0.177

2.3

clm800hzn152mp30

1500

25×25

0.177

2.3

clm800hzn152mq25

1500

30×20

0.2

1.4

clm800hzn152mr20

1800

22×35

0.147

2.5

clm800hzn182mp35

1800

25×30

0.147

2.5

clm800hzn182mq30

2200

22×40

0.155

2.7

clm800hzn222mp40

2200

25×30

0.155

2.7

clm800hzn222mq30

2200

30×25

0.155

2.7

clm800hzn222mr25

2200

35×20

0.135

1.7

clm800hzn222ma20

2700

22×45

0.098

2.8

clm800hzn272mp45

2700

25×35

0.098

2.8

clm800hzn272mq35

2700

30×30

0.098

2.8

clm800hzn272mr30

3300

22×50

0.085

3.2

clm800hzn332mp50

3300

25×40

0.085

3.2

clm800hzn332mq40

3300

30×30

0.085

3.2

clm800hzn332mr30

3900

25×45

0.08

3.6

clm800hzn392mq45

3900

30×35

0.08

3.6

clm800hzn392mr35

4700

25×50

0.065

4.1

clm800hzn472ma50

4700

30×40

0.072

4.1

clm800hzn472mr40

5600

30×45

0.055

4.6

clm800hzn562mr45

5600

35×35

0.055

4.6

clm800hzn562ma35

6800

30×50

0.045

5.2

clm800hzn682mr50

6800

35×40

0.045

5.2

clm800hzn682ma40

8200

35×50

0.04

5.8

clm800hzn822ma50

8200

40×40

0.04

5.83

clm800hzn822mu40

频率（hz）

50

60

120

500

1k

10k

16～100vc

0.93

0.95

1.00

1.05

1.08

1.15

160～550vc

0.75

0.80

1.00

1.20

1.25

1.40
